PM200DVA120

PM200DVA120 Description

PM200DVA120 is a power module that consists of two IGBT (Insulated Gate Bipolar Transistor) devices and two diodes manufactured by Mitsubishi Electric Corporation. The PM200DVA120 power module is designed for use in high power applications, such as motor control, power supplies, and industrial equipment. It has a voltage rating of 1200V and a current rating of 200A, making it suitable for use in high power systems. The module features a compact and robust design with an insulated ceramic baseplate, which ensures reliable operation even in harsh environments. It also has a built-in temperature sensor and an over-temperature protection circuit, which helps to prevent overheating and ensure safe and stable operation. The PM200DVA120 power module has a range of protection features, including overvoltage protection (OVP), overcurrent protection (OCP), and short-circuit protection (SCP), to ensure safe and reliable operation. It also has a high level of efficiency and reliability, which helps to reduce energy consumption and maintenance costs. Overall, the PM200DVA120 power module is a high-quality and reliable component that provides efficient power control solutions for various high-power applications. It is commonly used in motor control, power supplies, and other applications that require high voltage and high current capabilities.

Summary of Features

PM200DVA120 is a(n) 1200V, 200A Intelligent Power Modules. .

Target Applications

PM200DVA120 and other IGBT (Insulated Gate Bipolar Transistor) transistor modules find applications in various industries and systems where high power switching is required. Some common applications include:

• Industrial Drives: IGBT modules are widely used in variable frequency drives (VFDs) and servo drives for controlling the speed and torque of electric motors in industrial machinery.
• Renewable Energy: Inverter systems for solar photovoltaic (PV) and wind power generation utilize IGBT modules for converting DC power from solar panels or wind turbines into AC power suitable for the grid.
• Electric Vehicles (EVs): IGBT modules are employed in the power electronics of electric and hybrid vehicles for converting the battery DC voltage to the AC voltage required by the electric motor.
• Railway Traction: IGBT modules are utilized in traction systems for electric trains and trams to control the speed and acceleration of the vehicles.
• Power Supplies: High-power IGBT modules are used in switch-mode power supplies (SMPS) and uninterruptible power supplies (UPS) for efficient power conversion and voltage regulation.
• Welding Equipment: Inverter-based welding machines use IGBT modules for precise control of welding current and voltage.
• HVAC Systems: Heating, ventilation, and air conditioning (HVAC) systems utilize IGBT modules in variable speed compressors and fans for energy-efficient operation.
• Medical Equipment: IGBT modules are employed in various medical equipment such as MRI machines, X-ray generators, and medical lasers for power control and conversion.
• Power Transmission: High-voltage direct current (HVDC) transmission systems utilize IGBT modules in converters for efficient long-distance power transmission.
• Motor Drives: IGBT modules are used in motor drives for controlling the speed and torque of large industrial motors in applications such as pumps, fans, and compressors.

These are just some examples, and the use of IGBT modules continues to expand into new areas as technology advances and the demand for high-power switching solutions grows.
