FZ400R17KE3

FZ400R17KE3 Description

is an Insulated Gate Bipolar Transistor (IGBT) module designed for high power switching applications. It is part of the IGBT4 series from Infineon Technologies. The module has a maximum collector-emitter voltage of 1700V and a maximum collector current of 400A. It has a low on-state voltage drop and high switching speed, making it suitable for high-frequency switching applications. The FZ400R17KE3 is designed with a 7th generation IGBT chip and an advanced diode for improved performance and efficiency. It also features a low-inductance module design for reduced switching losses and a longer lifespan. The module is equipped with a thermistor for temperature monitoring and protection against over-temperature conditions. It also has a built-in driver and protection features such as short-circuit protection, over-current protection, and under-voltage lockout. Overall, the FZ400R17KE3 is a reliable and high-performance IGBT module designed for a wide range of applications including motor drives, power supplies, renewable energy systems, and industrial equipment.

Summary of Features

FZ400R17KE3 is a(n) 1700V, 400A IGBT Modules. .

Target Applications

FZ400R17KE3 and other IGBT (Insulated Gate Bipolar Transistor) transistor modules find applications in various industries and systems where high power switching is required. Some common applications include:

• Industrial Drives: IGBT modules are widely used in variable frequency drives (VFDs) and servo drives for controlling the speed and torque of electric motors in industrial machinery.
• Renewable Energy: Inverter systems for solar photovoltaic (PV) and wind power generation utilize IGBT modules for converting DC power from solar panels or wind turbines into AC power suitable for the grid.
• Electric Vehicles (EVs): IGBT modules are employed in the power electronics of electric and hybrid vehicles for converting the battery DC voltage to the AC voltage required by the electric motor.
• Railway Traction: IGBT modules are utilized in traction systems for electric trains and trams to control the speed and acceleration of the vehicles.
• Power Supplies: High-power IGBT modules are used in switch-mode power supplies (SMPS) and uninterruptible power supplies (UPS) for efficient power conversion and voltage regulation.
• Welding Equipment: Inverter-based welding machines use IGBT modules for precise control of welding current and voltage.
• HVAC Systems: Heating, ventilation, and air conditioning (HVAC) systems utilize IGBT modules in variable speed compressors and fans for energy-efficient operation.
• Medical Equipment: IGBT modules are employed in various medical equipment such as MRI machines, X-ray generators, and medical lasers for power control and conversion.
• Power Transmission: High-voltage direct current (HVDC) transmission systems utilize IGBT modules in converters for efficient long-distance power transmission.
• Motor Drives: IGBT modules are used in motor drives for controlling the speed and torque of large industrial motors in applications such as pumps, fans, and compressors.

These are just some examples, and the use of IGBT modules continues to expand into new areas as technology advances and the demand for high-power switching solutions grows.
