BSM30GP60

BSM30GP60 Description

is a type of Insulated Gate Bipolar Transistor (IGBT) module produced by Mitsubishi Electric, a leading manufacturer of power electronics components. It is designed for use in high-power switching applications, such as motor drives, renewable energy systems, and industrial automation. The IGBT module has a current rating of 30A and a voltage rating of 600V. It consists of two IGBTs and two anti-parallel diodes in a half-bridge configuration, which allows it to switch high power loads efficiently. The BSM30GP60 IGBT module is designed with low-on resistance and high-speed switching characteristics, which result in low power dissipation and high efficiency. It is also designed with a compact and robust package, which provides excellent thermal performance and high resistance to mechanical stress. The module is also equipped with an electrical interlock system that prevents incorrect module insertion, ensuring safe and reliable operation. Overall, the BSM30GP60 IGBT module is a high-performance device that provides efficient and reliable power switching capabilities in high-power applications. Its high current and voltage ratings, combined with its low-on resistance and high-speed switching characteristics, make it suitable for use in demanding power electronics applications that require high efficiency and precise control.

Summary of Features

BSM30GP60 is a(n) 600V, 50A IGBT Modules. .

Target Applications

BSM30GP60 and other IGBT (Insulated Gate Bipolar Transistor) transistor modules find applications in various industries and systems where high power switching is required. Some common applications include:

• Industrial Drives: IGBT modules are widely used in variable frequency drives (VFDs) and servo drives for controlling the speed and torque of electric motors in industrial machinery.
• Renewable Energy: Inverter systems for solar photovoltaic (PV) and wind power generation utilize IGBT modules for converting DC power from solar panels or wind turbines into AC power suitable for the grid.
• Electric Vehicles (EVs): IGBT modules are employed in the power electronics of electric and hybrid vehicles for converting the battery DC voltage to the AC voltage required by the electric motor.
• Railway Traction: IGBT modules are utilized in traction systems for electric trains and trams to control the speed and acceleration of the vehicles.
• Power Supplies: High-power IGBT modules are used in switch-mode power supplies (SMPS) and uninterruptible power supplies (UPS) for efficient power conversion and voltage regulation.
• Welding Equipment: Inverter-based welding machines use IGBT modules for precise control of welding current and voltage.
• HVAC Systems: Heating, ventilation, and air conditioning (HVAC) systems utilize IGBT modules in variable speed compressors and fans for energy-efficient operation.
• Medical Equipment: IGBT modules are employed in various medical equipment such as MRI machines, X-ray generators, and medical lasers for power control and conversion.
• Power Transmission: High-voltage direct current (HVDC) transmission systems utilize IGBT modules in converters for efficient long-distance power transmission.
• Motor Drives: IGBT modules are used in motor drives for controlling the speed and torque of large industrial motors in applications such as pumps, fans, and compressors.

These are just some examples, and the use of IGBT modules continues to expand into new areas as technology advances and the demand for high-power switching solutions grows.
